NC Quantum Apex catheter

NC QUANTUM APEX™

SKU:

54386

The NC Quantum Apex Dilation Catheter is a dual-lumen, coaxial balloon catheter designed for percutaneous transluminal angioplasty. Featuring an atraumatic tip, precise balloon expansion, and specialized coatings, it ensures safe and effective lesion crossing.

  • Safe Payments
    Payment upon receipt of goods, Payment by card in the department, Google Pay, Online card, -5% discount in case of payment

  • Worldwide Delivery
    The Consumer Protection Act does not provide for the return of this product of proper quality.

  • Money Back Guarantee
    The Consumer Protection Act does not provide for the return of this product of proper quality.

Description

The NC Quantum Apex™ Dilation Catheter is engineered for high-performance coronary angioplasty. Its dual-lumen, coaxial distal shaft allows stable and reliable navigation. The balloon is designed to inflate to a known diameter and length at the recommended pressure, ensuring precision and predictability during angioplasty.

The catheter features an atraumatic distal tip, facilitating smooth advancement through the vasculature and crossing of stenotic or previously stented regions. To further enhance performance, the catheter surface integrates hydrophilic and hydrophobic coatings applied to different segments, providing optimal balance between trackability, pushability, and control.

With its robust design, the NC Quantum Apex™ is ideal for challenging lesions where accurate dilatation and safety are critical.



Product Code Length / Diameter (mm) Tip Profile (in/mm) Nominal Pressure (ATM/kPa) Rated Burst Pressure (ATM/kPa)
H749391240620 6 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240622 6 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391240625 6 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391240627 6 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391240630 6 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240632 6 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391240635 6 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391240637 6 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391240640 6 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240645 6 / 4.50 0.017 / 0.43 12 (1216) 18 (1824)
H749391240650 6 / 5.00 0.017 / 0.43 12 (1216) 18 (1824)
H749391240820 8 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240822 8 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391240825 8 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391240827 8 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391240830 8 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240832 8 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391240835 8 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391240837 8 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391240840 8 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391240845 8 / 4.50 0.017 / 0.43 12 (1216) 18 (1824)
H749391240850 8 / 5.00 0.017 / 0.43 12 (1216) 18 (1824)
H749391241220 12 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241222 12 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391241225 12 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391241227 12 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391241230 12 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241232 12 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391241235 12 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391241237 12 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391241240 12 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241245 12 / 4.50 0.017 / 0.43 12 (1216) 18 (1824)
H749391241250 12 / 5.00 0.017 / 0.43 12 (1216) 18 (1824)
H749391241520 15 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241522 15 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391241525 15 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391241527 15 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391241530 15 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241532 15 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391241535 15 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391241537 15 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391241540 15 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391241545 15 / 4.50 0.017 / 0.43 12 (1216) 18 (1824)
H749391241550 15 / 5.00 0.017 / 0.43 12 (1216) 18 (1824)
H749391242020 20 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391242022 20 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391242025 20 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391242027 20 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391242030 20 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391242032 20 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391242035 20 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391242037 20 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391242040 20 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391242045 20 / 4.50 0.017 / 0.43 12 (1216) 18 (1824)
H749391242050 20 / 5.00 0.017 / 0.43 12 (1216) 18 (1824)
H749391243020 30 / 2.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391243022 30 / 2.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391243025 30 / 2.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391243027 30 / 2.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391243030 30 / 3.00 0.017 / 0.43 12 (1216) 20 (2026)
H749391243032 30 / 3.25 0.017 / 0.43 12 (1216) 20 (2026)
H749391243035 30 / 3.50 0.017 / 0.43 12 (1216) 20 (2026)
H749391243037 30 / 3.75 0.017 / 0.43 12 (1216) 20 (2026)
H749391243040 30 / 4.00 0.017 / 0.43 12 (1216) 20 (2026)

Additional information

Product Code

H749391240620, H749391240622, H749391240625, H749391240627, H749391240630, H749391240632, H749391240635, H749391240637, H749391240640, H749391240645, H749391240650, H749391240820, H749391240822, H749391240825, H749391240827, H749391240830, H749391240832, H749391240835, H749391240837, H749391240840, H749391240845, H749391240850, H749391241220, H749391241222, H749391241225, H749391241227, H749391241230, H749391241232, H749391241235, H749391241237, H749391241240, H749391241245, H749391241250, H749391241520, H749391241522, H749391241525, H749391241527, H749391241530, H749391241532, H749391241535, H749391241537, H749391241540, H749391241545, H749391241550, H749391242020, H749391242022, H749391242025, H749391242027, H749391242030, H749391242032, H749391242035, H749391242037, H749391242040, H749391242045, H749391242050, H749391243020, H749391243022, H749391243025, H749391243027, H749391243030, H749391243032, H749391243035, H749391243037, H749391243040
